Endoscopic Image System with Light Source for Endoscope 2-1 E22b with Output Display

1 / 5

Endoscopic Image System with Light Source for Endoscope 2-1 E22b with Output Display

Still deciding? Get samples of $ !

Request Sample

Send Inquiry

Product Description

Basic Specifications

Model NO.

E22B

Certification

CE, ISO13485

Image Sensor

1/2'' Coms

Resolution

1920X1080p IPX8 Waterproof

Horizontal Resolution

1200tvl

Screen Size

7'' with Output Display

Storage

U Disk / Hard Disk / SD Card

Video Recording

1920X1080p, MP4 Format

Photograph

1920X1080p 8 Megapixel JPG

Video Output

USB 2.0x2, HDMI1.4, DVI, CVBS, SDI

LED Life Span

50,000 Hours

Origin

China

Product Description

1080P Full HD Endoscope Camera System with integrated Light Source. Designed for delicate medical imaging, featuring advanced noise reduction and high-contrast diagnostic capabilities.

The resolution 1080P (1920 x 1080) presents delicate images with stronger noise reduction, sharpening, brightness, contrast, and extinction functions. It is perfectly engineered to meet the needs of doctors in complex surgical treatments and diagnostic procedures.

Technical Parameters

Parameter	Details	Feature	Value
Models	E22A / E22B	Touch Screen	7 inch (E22B Display)
Image Sensor	1/2'' CMOS	Storage	U disk / Hard disk
Resolution	1920x1080p	Photograph	2 Megapixel JPG
LED Life Span	50,000 Hours	Signal Output	HDMI, SDI, USB, DVI, CVBS
Illumination	> 2,000,000 Lux	Net Weight	5.8 kgs

Configurations & Setup

E22B with Monitor View:

E22B with Medical Trolley:

Quality Certificates

Frequently Asked Questions

What is the resolution of the E22B endoscope camera?

The E22B system provides Full HD 1080P resolution (1920x1080 pixels), ensuring sharp and clear images for surgical procedures.

Can the device record videos and take photos?

Yes, it supports both high-quality video recording in MP4 format and still photography with 8-megapixel JPG output.

What kind of light source is integrated into the system?

The system features a high-intensity LED light source with an illumination intensity of over 2,000,000 Lux and a life span of approximately 50,000 hours.

What are the available video output signals?

The device is highly versatile, offering USB 2.0, HDMI 1.4, DVI, CVBS, and SDI outputs to connect with various medical monitors.

Is the camera head waterproof?

Yes, the camera head is IPX8 waterproof rated, making it suitable for standard medical disinfection and surgical environments.

Does the E22B model include a built-in display?

Yes, the E22B model specifically includes a 7-inch touch screen output display for convenient immediate viewing and control.
